TeraStation™ WS5220DNW6

WSS 2016 and 10 GbE - 2-Bay Business NAS

Product Data Sheet buy now

TeraStation™ WS5220DNW6

WSS 2016 and 10 GbE – 2-Bay Business NAS

Buffalo’s TeraStation™ WS5220DNW6 with Windows Storage Server 2016 (workgroup edition) combines two hard drive, high-performance network attached storage with the power and convenience of Windows operating system and is fully populated HDD hard drives. The WS5220DN comes equipped with powerful Intel® Atom™ Processor and 8GB of fast DDR3 memory installed. Buffalo’s TeraStation™ WS5220DN is an ideal solution for consolidating multiple file servers into a single solution that enables cost reduction and lowering the overhead on your existing servers for other workloads.

CPU Speed

1.5GHz

RAM

8GB ECC DDR4

Number of Bays

2

Supported RAID Levels

JBOD, 0, 1

Enjoy the benefits of WSS 2016 NAS

Windows Server 2016 Workgroup provides a simple and cost-effective enterprise-class solution that is application- and user-oriented. With Windows Server 2016 Workgroup, you can leverage your data center capacity, deliver world-class performance for your Microsoft workloads, and achieve affordable business continuity scenarios with multiple networks and high service availability and disaster recovery at the highest level.Read more

Hot-swap function increases data security

With the hot swap function, the TeraStation™ automatically switches off the defective hard disk even if one hard disk fails, so that it can be replaced safely without interrupting work or losing data.

Including Buffalo VIP service

Replacement of defective hard disks within 24 hours

If you want to replace a defective hard disk, just let us know. If your order is in the system before 12 noon and the hard drives are in stock, they will be replaced within 24 hours. Applies within the 3 year warranty for each TeraStation and LinkStation NVR sold in the EU. (Outside the EU it can take longer).

More info

iSCSI target support

Works simultaneously as NAS and iSCSI target.

3 year warranty

This product has a standard warranty of 3 years. Check for other possibilities of warranty extension.

Replication with TeraStation

By replication, a folder in two separate TeraStations™ is synchronized almost in real time. This only happens in one direction (not bi-directional) – from the source to the destination. This function can be set up in LAN and WAN. WAN setup includes remote connection via port forwarding and VPN setup.

Learn More

Replication with TeraStation

By replication, a folder in two separate TeraStations™ is synchronized almost in real time. This only happens in one direction (not bi-directional) – from the source to the destination. This function can be set up in LAN and WAN. WAN setup includes remote connection via port forwarding and VPN setup.

Learn More

High transmission speed

The 10GbE connectivity impresses with exceptional speed.

Hardware System

Form factor
Desktop
CPU Type
Intel Atom C3338
CPU Speed
1.5GHz
RAM
8GB ECC DDR4
Drive Interface
SATA 3.0 (6Gb/s)
Installed OS
Windows Storage Server 2016
OS Version
WSS 2016 Workgroup Edition
Included user licenses
No CAL (Client-Access Licenses) required.

Internal Hard Drives

Type of Drive
NAS HDD
Number of Bays
2
Total Capacity
4TB, 8TB

LAN Interface

Connector Type
RJ-45
LAN Ports
1 x 10GbE, 2 x 1GbE
Max Transmission Rate
2x 10/100/1000Mbps, 1x 100/1000Mbps / 2.5/5/10Gbps

USB Interface

Connector Type
USB 3.0 Type A
USB 3.0 Ports
2
Max Transmission Rate
Max: 5 Gb/s

Other

Client OS
Windows 10, 8.1, 7 Windows Server 2016, 2012 R2, 2012, 2008 R2, 2008 macOS 10.13, 10.12, 10.11
Support
Standard Warranty 3 years, 24 hour HDD exchange, Technical Support Hotline
Dimensions
170 (W) x 170 (H) x 230 (D) mm
Weight
5 kg
Operating Environment
0-40°C, humidity 10-85% (non-condensing)
Power Supply
Internal AC 100-240V Universal, 50/60Hz
Power Consumption (max.)
85 W

Software System

Supported RAID Levels
JBOD, 0, 1

Protocol Support

Networking
TCP/IP
File Sharing
CIFS/SMB, NFS
Protocol Support
TCP/IP, CIFS/SMB, DFS replication, NFS, LDAP, NTP
Other
Disk quota, User quota, Wake on LAN, Print Server Support
Active Directory support
Yes
Active Directory users
Unlimited

Backup

Realtime Backup
DFS replication
Replication
Yes
Backup Software Licenses
11 licenses NovaBACKUP Buffalo Edition for Windows Clients: 1 server license, 10 PC licenses
Cloud Support
Microsoft Azure, compatible 3rd party tools

Product Part Numbers

Product Code
WS5220DN08W6EU - 8TB, WS5220DN04W6EU - 4TB
Note
1TB = 1, 000, 000, 000, 000Bytes. Actual data throughput will vary depending upon environment factor.
