MiniStation™

Attractive and nimble. Portable Hard Drive.

Product Data Sheet

MiniStation™

Attractive and nimble. Portable Hard Drive.

Buffalo’s MiniStation™ Portable Hard Drive series are sleek and lightweight portable USB Storage devices, utilising cutting edge USB 3.0 technology in a slim form factor.

Total Capacity

1TB, 2TB

Max Transmission Rate

5 Gb/s

Dimensions

76 x 115 x 14 mm - 1TB, 76 x 115 x 19.5 mm - 2TB

Weight

165 g (1TB) / 225 g (2TB)

SuperSpeed USB 3.0

Equipped with super-fast USB 3.0, but also supports standard USB 2.0 port, no adjustment required, just connect to a USB 2.0 port.

Power supply via USB and integrated USB cable

  • No external power supply or power supply is required for the drive, as it is powered via USB. This makes the highly mobile drive perfect for travelling, as less cables are required
  • USB cables can be attached to the case for maximum mobility

Plug and play

Plug and play connectivity: Simply plug the hard drive into a USB port on your computer or other device. No driver installation or complicated configuration is required.

Internal Hard Drives

Number of Drives
1
Total Capacity
1TB, 2TB
Drive Interface
SATA

USB Interface

Standard Compliance
USB 3.0
Connector Type
USB 3.0 Type B
USB 3.0 Ports
1
Max Transmission Rate
5 Gb/s

Other

Client OS
Windows® 10 / 8.1 / 8 / 7 / Vista™; Mac® OS X 10.7 or later
Dimensions
76 x 115 x 14 mm - 1TB, 76 x 115 x 19.5 mm - 2TB
Weight
165 g (1TB) / 225 g (2TB)
Operating Environment
5-35°C, 20-80% (non-condensing)
Power Supply
Bus powered
Power Management System
No
Warranty Period
2 Years
Available Colours
Black
Special Features
Lightweight design

Product Part Numbers

Product Code
HD-PCF1.0U3BD-WR (1TB), HD-PCF2.0U3BD-WR (2TB)
Manuals / Setup / Latest Product Information
Documentation & Software 13-04-2018
Utilities
Release notes 1.40 Windows 26-09-2016
TurboPC EX 1.40 Windows 26-09-2016
